40 x 20 x 5mm C Section Channel - BSEN10025-2 S275JR
Save up to 15%
Save upto 15% on all general steel
Expires 30th April 2024
LHTFC-40-20-5.0-2.9-S275
Available
Bulk discounts available:
Buy 2 to 3 metres at £16.33 per metre
Buy 3 to 4 metres at £14.00 per metre
Buy 4 to 5 metres at £11.66 per metre
Buy 5 or more metres at £9.32 per metre
check delivery cost
login to save
ask a questionProduct Specifications
Depth Of Section
40.0mm
Flange Thickness
5.5mm
Grade
BSEN10025-2 S275JR
Length
6000mm
Web Thickness
4.8mm
Weight (per/m)
2.9kg
Width Of Section
20.0mm
Product Description
Tapered Flange Channels, also known as TFCs, are a type of structural steel product used primarily in the construction industry. They are designed with a sloping flange on one side, which provides increased strength and stability while reducing weight.Tapered Flange Channels are popular in construction applications because their tapered flanges allow for more efficient weight distribution, which reduces the amount of steel needed to achieve the same level of strength as traditional steel channels. This allows for easier transportation and installation due to the lighter weight of the product.
