Parallel Flange Channel

PFC steel, meaning Parallel Flange Channel steel, is a structural steel section with a C-shaped profile and parallel flanges. Also known as C Section, C Channel or U Channel steel, Parallel Flange Channels combine strength and rigidity with a profile that is straightforward to connect and fabricate, making them widely used across construction and engineering projects.

Read more

PFC steel, meaning Parallel Flange Channel steel, is a structural steel section with a C-shaped profile and parallel flanges. Also known as C Section, C Channel or U Channel steel, Parallel Flange Channels combine strength and rigidity with a profile that is straightforward to connect and fabricate, making them widely used across construction and engineering projects.

BM Steel stocks a broad range of PFC steel and rolled steel channel sizes for UK projects. Available Parallel Flange Channel sizes range from 100 x 50 x 10KG to 300 x 100 x 46KG, with different section depths, flange widths, web thicknesses, flange thicknesses and weights available to suit different structural requirements. PFC sections are also available in different structural steel grades and lengths across the range.

The size of a steel channel is commonly identified by its section depth, flange width and approximate weight per metre. For example, a 150 x 75 x 18KG PFC has a section depth of 150mm, a flange width of 75mm and weighs approximately 18kg per metre. Comparing these measurements alongside the web thickness, flange thickness and steel grade can help identify the appropriate section for a specific project.

Parallel Flange Channels are commonly used for structural frameworks, supports, bases and other load-bearing steelwork. Their parallel flange design supports straightforward alignment, welding, drilling and connection with other structural components, making PFC steel suitable for commercial, industrial and infrastructure applications.

Browse BM Steel's range of Parallel Flange Channels to compare the available sizes of steel channel and select the specification required for your project.

Read less

View Parallel Flange Channel FAQS

FILTERS14 products
Filter
Close
Weight (per/m)
Depth Of Section
Width Of Section
Web Thickness
Flange Thickness
Grade
Length
Price
Additional Filters
Sort By







Per Page

14 products
DESIGNATION PRICE (PER/M)
100 x 50 x 10KG from £22.03 inc VAT VIEW
125 x 65 x 15KG from £31.97 inc VAT VIEW
150 x 75 x 18KG from £38.66 inc VAT VIEW
150 x 90 x 24KG from £51.62 inc VAT VIEW
180 x 75 x 20KG from £43.85 inc VAT VIEW
180 x 90 x 26KG from £56.38 inc VAT VIEW
200 x 75 x 23KG from £50.54 inc VAT VIEW
200 x 90 x 30KG from £64.15 inc VAT VIEW
230 x 75 x 26KG from £55.51 inc VAT VIEW
230 x 90 x 32KG from £69.55 inc VAT VIEW
260 x 75 x 28KG from £59.62 inc VAT VIEW
260 x 90 x 35KG from £75.17 inc VAT VIEW
300 x 90 x 41KG from £89.42 inc VAT VIEW
300 x 100 x 46KG from £98.28 inc VAT VIEW

Parallel Flange Channel FAQs

Is PFC steel the same as C Channel steel?

PFC steel is a type of C-shaped structural steel channel and may also be referred to as C Channel or C Section steel. PFC specifically stands for Parallel Flange Channel and describes a channel section with parallel flange faces.

When selecting C Channel steel, the section dimensions, weight, thickness and grade should be checked to make sure the product meets the required specification.

What sizes do PFC steel channels come in?

BM Steel stocks PFC steel in sizes ranging from 100 x 50 x 10KG to 300 x 100 x 46KG. Different section depths, flange widths, web thicknesses, flange thicknesses and weights are available across the range.

The required PFC size will depend on the structural specification and load requirements of the individual project.

What is the difference between Parallel Flange Channel and Tapered Flange Channel?

The main difference between Parallel Flange Channels and Tapered Flange Channels is the shape of their flanges. A Parallel Flange Channel has flanges with parallel faces, while a Tapered Flange Channel has flanges that change in thickness across their width.

Parallel flanges can make alignment and connection more straightforward during fabrication, while the appropriate channel type will depend on the structural requirements of the project.


What does PFC mean in steel?

PFC stands for Parallel Flange Channel. PFC steel is a structural steel section with a C-shaped profile and two parallel flanges.

Parallel Flange Channels are commonly used in construction, fabrication and engineering for structural frameworks, supports and load-bearing applications.


How are steel channel sizes measured?

Steel channel sizes are commonly identified by the depth of the section, flange width and approximate weight per metre. For example, a 150 x 75 x 18KG PFC has a section depth of 150mm, a flange width of 75mm and weighs approximately 18kg per metre.

Web thickness, flange thickness and steel grade should also be considered when comparing different channel sections.
